T-213H 10a Handheld Micro-Ohm Meter From 10uΩ To 50kΩ
The T-213H handheld Micro-ohm meter also known as transformer DC resistance tester, DC resistance fast tester and grounding continuity tester, adopts Microprocessor technology and four wire method for testing, which is safe, precise and reliable. It is mainly used to measure the resistance of instrument transformer winding, winding resistance of transformer, conduction test of grounding down lead, conductor resistance of cable, switch, connector, contact resistance of relay, coil, motor, and connection electricity between metal components of equipment shell, lightning strip, ground beam, structure, cabinet, steel bar, water pipe, window, guardrail, radiator, assembly line and other objects resistance test. It is widely used in telecommunication, electricity, meteorology, computer room, oil field, power distribution line, transmission line of iron tower, gas station, factory grounding grid, lightning rod, etc.
Function
- Testing winding resistance of instrument transformer;
- Measure DC resistance of transformer;
- Testing continuity of grounding grid connection;
- Testing conductor resistance of cable;
- Testing contact resistance of switch;
- Testing resistance of connector;
- Testing resistance of relay;
- Testing resistance of coil;
- Testing resistance of copper pillar;
- Testing motor winding resistance;
- Testing metal riveting resistance;
- Testing connection resistance test between metal components;
- Testing low value resistance;
- Testing contact resistance etc..
Features
- High accuracy 0.2%;
- Wide measuring range 10.0uΩ-50.00kΩ;
- Test current 10A, 5A, 1A, 0.1A, 10mA, 1mA optional;
- With 5.6 inch color touch LCD display;
- Storage 500groups test data;
- Handheld and lightweight, weighs only 1kg;
- Easy to operate, auto test resistance value;
- Four wire method for testing resistance;
- With rechargeable lithium battery;
- Designed for rugged field use;
- Communication: with USB port;
Parameters
| Electrical parameters | |
|---|---|
| Power supply | DC 12.6V 2500mAh lithium battery |
| Test range | 10.0uΩ-50.00KΩ |
| Test current output | 10A, 5A, 1A, 0.1A, 10mA, 1mA |
| Test method | Four wire test |
| Test range | Accuracy and resolution |
| 10.0uΩ~1000.0uΩ (10A) | Accuracy 0.2%FS±2bit Resolution 0.1uΩ |
| 1.00mΩ~100.00mΩ (10A) | Accuracy 0.2%FS±2bit Resolution 0.01mΩ |
| 100.0mΩ~1000.0mΩ (5A) | Accuracy 0.2%FS±2bit Resolution 0.1mΩ |
| 1.000Ω~10.000Ω (1A) | Accuracy 0.2%FS±2bit Resolution 0.001Ω |
| 10.00Ω~100.00Ω (100mA) | Accuracy 0.2%FS±2bit Resolution 0.01Ω |
| 100.0Ω~1000.0Ω (10mA) | Accuracy 0.2%FS±2bit Resolution 0.1Ω |
| 1.000KΩ~10.000KΩ (1mA) | Accuracy 0.2%FS±2bit Resolution 0.001KΩ |
| 10.00KΩ~50.00KΩ (1mA) | Accuracy 0.2%FS±2bit Resolution 0.01KΩ |
| Accuracy | 0.2%FS±2bit |
| Resolution | Min 0.1μΩ |
| Max storage volume | 500 sets |
| LCD | 108 mm×65mm color touch LCD display |
| Communication | USB port |
| Maximum short circuit current | 10A |
| Overload protection | Yes |
| Automatic discharge | Yes |
| Test Cable | 5m |
| Test method | Four fire |
| Degree of protection | IP53 |
| Insulation Resistance | >10MΩ (500V between circuit and shell) |
| Withstand voltage | AC 3.7KV/RMS (between circuit and housing) |
| Standard | IEC61010-4-3, IEC61010-1, CAT Ⅲ 600V, Pollution Level 2, JJG724-1991《verification regulation of DC digital ohmmeter》, JJG166-1993《Verification regulation of DC resistor》, DL/T967-2005 《Verification regulation of loop resistance tester and DC resistance fast tester》 |
| Mechanical parameters | |
| Dimension (L×W×H)(mm) | 240×188×85 |
| Weight (kg) | 1 (with battery); 0.85 (test cable) |
| Environmental conditions | |
| Operating temperature | -20°C to 50°C |
| Storage temperature | -40°C to 70°C |
| Relative humidity | ≤95%RH |
