P18 100A voltage Output 2M Hz bandwidth Class 0.1 AC Current Clamp

100A current clamp

The round jaw design on the P18 Series AC current clamp along with the high content nickel metal core makes them well suited for power quality applications where high accuracy and low phase shift along with wide frequency are important. Measurement range is 1mA to 120A. The P18 is a general purpose 100A AC current clamp designed for use with DMMs, power loggers and energy meter calibration instruments that have a current input. It has a 1000:1 ratio and output of 1mA per amp or 1mV per amp measured in the jaw. The P18 has an integral 2.5m lead terminated. The rounded jaw design on this current clamp makes it well-suited for power applications where high accuracy 0.1% and low phase shift and wide frequency response are important..



Applications

  • Power quality analyzer(PQA)
  • power and harmonic meters
  • Phase angle meter
  • Energy meter calibrator
  • Measuring around cable bundles
  • Power load monitoring
  • Data logging/recording
  • Waveform analysis(oscilloscopes meter)


Features

  • Measurement range of 1mA to 120A AC
  • Improved ergonomic design & easy operation
  • High content nickel metal permalloy core
  • Frequency 10Hz-2MHz Bandwidth
  • Holding wire diameter: φ18mm
  • Conforms to EN 61010, 600V CAT III
  • Low phase shift for power measurement
  • Designed for DMMs, recorders, loggers, oscilloscopes, power and harmonic meters
  • UL, CE mark


Parameters

Electrical parameters
Ratio 1000: 1 or 2000:1 (customized)
Accuracy class 0.1%, 0.2%
Primary current 0 - 100A AC or 0-200A AC
Secondary current 0 - 100mA AC or 0 - 200mA AC (customized)
Secondary voltage 0 - 100mV AC, 0 - 1V AC or 0-5V AC (customized)
Max. Cont. Input current 120A or 240A
Load capacity ≤4Ω
Over voltage category CAT III 600V
Output signal (AC current) From 0 to 200mA AC at nominal input current
Output signal (AC voltage) From 0 to 5V AC at nominal input current
Frequency range 10Hz-2MHz
Dielectric strength 3KV 50Hz/60Hz at 1minute
Temperature range '-40°C to +55°C
Output 2.5 meter cable with D01 or BNC connector
Max. voltage not insulated conductors 600 V
Standard EN 61010-1, EN 61010-2-032, IEC60044-1
Installation clamp type
Output mode lead output(2.5m, 5m or 10m)
Mechanical parameters
Dimensions (L x W x H) (mm) 52.5 x 137.5 x 28
Weight (g) 400
Holding wire diameter (mm) φ18
Max. jaw opening (mm) 18
Jaw color Red, yellow, blue, green, black
Material PC+ABS, UL94 V0

Technical parameters

Model Rate Current Max Current Secondary Current Coil Ratio Burden Resistance Accuracy
P18-10-1 10A 12A 10mA 1000:1 customized 0.1%
P18-10-2 10A 12A 5mA 2000:1 customized 0.1%
P18-20-1 20A 24A 20mA 1000:1 customized 0.1%
P18-20-2 20A 24A 10mA 2000:1 customized 0.1%
P18-100-1 100A 120A 100mA 1000:1 customized 0.1%
P18-100-2 100A 120A 50mA 2000:1 customized 0.1%
P18-200-1 200A 240A 200mA 1000:1 customized 0.1%
P18-200-2 200A 240A 100mA 2000:1 customized 0.1%
P18-10-12 10A 12A 10mA 1000:1 customized 0.2%
P18-10-22 10A 12A 5mA 2000:1 customized 0.2%
P18-20-12 20A 24A 20mA 1000:1 customized 0.2%
P18-20-22 20A 24A 10mA 2000:1 customized 0.2%
P18-100-12 100A 120A 100mA 1000:1 customized 0.2%
P18-100-22 100A 120A 50mA 2000:1 customized 0.2%
P18-200-12 200A 240A 200mA 1000:1 customized 0.2%
P18-200-22 200A 240A 100mA 2000:1 customized 0.2%
P18-10-10 10A 12A 100mV 1000:1 customized 0.1%
P18-10-20 10A 12A 100mV 2000:1 customized 0.1%
P18-20-10 20A 24A 100mV 1000:1 customized 0.1%
P18-20-20 20A 24A 100mV 2000:1 customized 0.1%
P18-100-10 100A 120A 100mV 1000:1 customized 0.1%
P18-100-20 100A 120A 100mV 2000:1 customized 0.1%
P18-200-10 200A 240A 100mV 1000:1 customized 0.1%
P18-200-20 200A 240A 100mV 2000:1 customized 0.1%
P18-10-11 10A 12A 1V 1000:1 customized 0.1%
P18-10-21 10A 12A 1V 2000:1 customized 0.1%
P18-20-11 20A 24A 1V 1000:1 customized 0.1%
P18-20-21 20A 24A 1V 2000:1 customized 0.1%
P18-100-11 100A 120A 1V 1000:1 customized 0.1%
P18-100-21 100A 120A 1V 2000:1 customized 0.1%
P18-200-11 200A 240A 1V 1000:1 customized 0.1%
P18-200-21 200A 240A 1V 2000:1 customized 0.1%
P18-10-12 10A 12A 5V 1000:1 customized 0.1%
P18-10-22 10A 12A 5V 2000:1 customized 0.1%
P18-20-12 20A 24A 5V 1000:1 customized 0.1%
P18-20-22 20A 24A 5V 2000:1 customized 0.1%
P18-100-12 100A 120A 5V 1000:1 customized 0.1%
P18-100-22 100A 120A 5V 2000:1 customized 0.1%
P18-200-12 200A 240A 5V 1000:1 customized 0.1%
P18-200-22 200A 240A 5V 2000:1 customized 0.1%
